Steiner MD448 User Manual

21
ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 2
DECK PARTS 60"
2-1 47-050 KNOB 4
64002-04 LOCKWASHER, EXT. 5/16 4
(SN 1001 - 4188)
2-2 60-526 SHIELD-TOP DECK 1
(SN 1001 - 1224)
60-544 SHIELD-TOP DECK 1
(SN 1225 - 4188)
4133299.17 SHIELD-TOP DECK 1
(SN 4189 - )
2-3 41-052 SPRING-EXT 0.875 X 6.750 1
2-4 6107645 CHAIN, IDLER ARM STOP 1
(SN 1001 - 1577)
2-5 64-534 HOOK-SPRING 1
(SN 1001 - 1577)
2-6 64141-2 NUT-WLF 1/4-20 4
2-7 29-010 GREASE FITTING-1/4 3
2-8 64164-12 KEY-1/4X1/4X1 SQ END 3
2-9 83-H16SPL BUSHING-H X 1" SPLIT TYPE3
2-10 83-BK72H SHEAVE- BK72H 3
2-11 64123-117 BOLT-HEX 1/2-13X1-1/2 1
2-12 83-012 IDLER-"V" 1/2" ID X 4-1/2" OD2
2-13 99-B12 WASHER-1/4 X 17/32 X 1-1/8 2
2-14 62-700 DECK-TOP 1
(SN 1001 - 1194)
62-729 DECK-TOP 1
(SN 1195 - 4188)
62-835 DECK-TOP 1
(SN 4189 - 5456)
62-868.7 UPR DK WLDMT 1
(SN 5457 - )
2-15 64025-09 HEX, NUT 1/2-13 2
2-16 64006-05 LOCKWSHR-HELICAL 1/2 2
2-17 64163-67 WASHER-.516X1X12GA 1
2-18 85-B29 BUSHING-.406 X .740 X .258 1
2-19 90-0814 BOLT-1/2 X 1-3/4 1
2-20 40-289 IDLER ARM 1
(SN 1001 - 1194)
40-290 IDLER ARM 1
(SN 1195 - 5456)
40-329.7 IDLER ARM 1
(SN 5457 - )
2-21 64141-4 NUT-WLF 3/8-16 18
2-22 64139-18 BLT-WLF 3/8-16X1-1/4 12
2-23 64139-21 BLT-WLF 3/8-16X3/4 5
2-24 62-694 DECK-MAIN 1
(SN 1001 - 1194)
62-727 DECK-MAIN 1
(SN 1195 - 4188)
62-834.17 DECK-MAIN 1
(SN 4189 - )
2-25 62-696.17 CHUTE-SIDE DISCHARGE 1
2-26 87-143 SPINDLE-MOWER 3
2-27 79-050 BLADE-20-1/2" .700 AIR LIFT 3
79-053 BLADE-20-1/2" 1-3/8 AIR LIFT3
2-28 99-B14 WASHER-1/4 X 1/2 ID X 3 OD 3
2-29 91-0810 BOLT-1/2 X 1-1/4 NF 3
2-30 64123-50 BOLT-HEX 3/8-16X1 1
2-31 64-799 WASHER-13/32 X 1-9/32 1
2-32 99-K38 BOLT-1/4 X 1-1/4 BH 2
(SN 1225 - )
2-33 64163-03 WSHR-.256IDX.62ODX18 2
(SN 1225 - )
2-34 64-687.7 SPACER 2
(SN 1010 - )
2-35 00-137 DECAL-SPIRAL INDICATOR 1
(SN 1225 - )
60-568.7 SUPPORT 1
(SN 1010 - )
2-36 56-059-17 TRIM-LOC-RUBBER 17" 1
(SN 1225 - )
2-37 06-010 CAP PLUG-1" 1
(SN 1225 - )
2-38 64-866 SHIM-SPINDLE 22 GA. 1
(1 PAIR OPTIONAL)
64-867 SHIM-SPINDLE 16 GA. 1
(1 PAIR OPTIONAL)
64-868 SHIM-SPINDLE 12 GA. 1
(1 PAIR OPTIONAL)
2-39 47-090 LATCH-RUBBER 3" LONG 3
(SN 4189 - )
2-40 04-008 POP RIVET-1/8 X 1/4 SS 6
(SN 4189 - )
2-41 04-007 POP RIVET-1/8 X 1/8 SS 6
(SN 4189 - )
2-42 64-900.7 BRCKT-TOP SHIELD LATCH 1
(SN 4189 - )
2-43 64139-02 BLT-WLF 1/4-20X1/2 2
(SN 4189 - )
2-44 64123-15 BOLT-3/8-16 X 3/4 3
2-45 64025-05 NUT-3/8-16 3
2-46 64006-03 LOCKWASHER-3/8 3
