25
ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FRAME PARTS 48"
FIGURE 4
4-1 64141-4 NUT-WLF 3/8-16 13
4-2 03-0610 CLEVIS PIN-3/8 X 1-1/4 1
4-3 02-PP0318 PRESTO PIN-3/32 X 2-5/16 1
4-4 29-010 GREASE FITTING-1/4 2
4-5 62-725.7 FRAME-HEIGHT ADJ 1
4-6 64123-70 BOLT-HEX 3/8-16X1-1/2 5
4-7 53-060 HUB CAP-FOR MOWER 2
4-8 99-AC12NFLOCKNUT-CENTER 3/4 NF 2
4-9 64163-06 WASHER-.768/.756X1.25X14 12
4-10 55-Z9504AB BALL BEARING-3/4 ID 4
4-11 64-807 SPACER 2
(SN 1001 -11310)
64-845.7 SHIELD-BEARING 2
(SN 1311 - )
4-12 4132783.7 CASTER, MOWER 2
4-13 64123-93 BLT-HEX 3/8-16X5 2
4-14 53-104 WHEEL-CASTER 2
(SN 1001 - 1711)
55-G527 BEARING-BALL 2
55-107 BEARING-5/8 ID X 1-3/8 OD 2
(OPT HD)
53-186 WHEEL-10.25 X 3.25 2
(SN 1712 - )
55-112 BRG-ROLLER 5/8 ID X 1-3/8 1
53-187 RETAINER 2
4-15 64163-16 WASHER-41/64X1, 3/8X12GA12
4-16 50-062 AXLE TUBE-CASTER WHL 2
4-17 64139-21 BLT-WLF 3/8-16X3/4 1
4-18 42-440.7 LINK-RIGHT LIFT 1
4-19 64123-16 BLT-HEX 3/8-16X1-1/4 3
4-20 64229-05 LOCKNUT, 1/2-13 NYLON 3
4-21 42-445.7 LINK-LEFT FRONT 1
4-22 42-443.7 LINK-HEIGHT ADJUSTMENT 1
4-23 64123-117 BOLT-HEX 1/2-13X1-1/2 1
4-24 90-0832 BOLT-1/2-13 X 4 2
4-25 64163-67 WASHER-.516X1X12GA 2
4-26 42-442 LINK-MIDDLE 1
4-27 62-724 FRAME-REAR ROLLER 1
(SN 1001 - 1577)
62-869.7 FRAME-REAR ROLLER 1
(SN 1578 - )
4-28 50-078.7 ROLLER-REAR 1
4-29 50-105 ROLLER-FRONT 1
85-B11 BEARING-3/4" WOOD RLR 2
4-30 50-074 AXLE-ANTI SCALP ROLLER 1
4-31 64123-219 BOLT-HEX 3/8-16X6 1
4-32 64141-6 NUT, 5/16-18 4
4-33 55-FB16016 BEARING-160 FLANGE 1" 2
4-34 64018-15 BLT-CRG 5/16-18X1 4
90-0510 BOLT-5/16 X 1-1/4 4
(SN 1001 - 1118)
99-K62 BOLT-FLANGE 5/16 X 1-1/4 4
(SN 1578 - )
4-35 64-663 BUSHING-ADJUSTER LINK 5
4-36 64-799 WASHER-13/32 X 1-9/32 18
4-37 29-045 GREASE FITTING-1/4 45 1
4-38 64-662 BUSHING-ADJUSTER LINK 2
