Steiner MD448 User Manual

23
ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 3
DECK PARTS 72"
3-1 47-050 KNOB 4
64002-04 LOCKWASHER, EXT. 5/16 4
(SN 1001 - 1837)
3-2 60-540.17 SHIELD-TOP DECK 1
(SN 1001 - 1016)
60-545.17 SHIELD-TOP DECK 1
(SN 1017 - 1837)
4133301.17 SHIELD-TOP DECK 1
(SN 1838 - )
3-3 41-051 SPRING-EXT 1.0 X 6.750 1
3-4 56-055-22 CHAIN-IDLER 1
(SN 1001 - 2301)
3-5 64-534 HOOK-SPRING 1
(SN 1001 - 2301)
3-6 64141-2 NUT-WLF 1/4-20 4
3-7 29-010 GREASE FITTING-1/4 3
3-8 64164-12 KEY-1/4X1/4X1 SQ END 3
3-9 83-H16SPL BUSHING-H X 1" SPLIT TYPE3
3-10 83-BK80H PULLEY- BK80H 3
3-11 64123-70 BOLT-HEX 3/8-16X1-1/2 1
3-12 83-034 IDLER-"V" 3/8" ID X 5" OD 2
3-13 64163-61 WSHR .81X.406X16GA 5
3-14 62-733 DECK-TOP 1
(SN 1001 - 1837)
62-840.7 DECK-TOP 1
(SN 1838 - 2301)
62-873.7 UPR DK WLDMT 1
(SN 2302 - )
3-15 64141-4 NUT-WLF 3/8-16 22
3-16 64-900 BRKT-TOP SHIELD LATCH 2
(SN 1838 - )
3-17 04-007 POP RIVET-1/8 X 18 SS 8
(SN 1838 - )
3-18 85-B29 BUSHING-.406X.740X.258 1
3-19 64123-87 BOLT-HEX 3/8-16X1-3/4 1
3-20 40-292 IDLER ARM 1
(SN 1001 - 2301)
40-329 IDLER ARM 1
(SN 2302 - )
3-21 64139-02 BLT-WLF 1/4-20X1/2 4
(SN 1838 - )
3-22 64139-18 BLT-WLF 3/8-16X1-1/4 12
3-23 64139-21 BLT-WLF 3/8-16X3/4 7
3-24 62-730.17 DECK-MOWER 1
(SN 1001 - 1837)
62-841.17 DECK-MOWER 1
(SN 1838 - )
3-25 60-54117 CHUTE-SIDE DISCHARGE 1
3-26 87-143 SPINDLE 3
3-27 79-068 BLADE-24-3/4" .700 AIR LIFT 3
79-069 BLADE-24-3/4" 1-3/8 AIR LIFT3
(OPTIONAL)
3-28 99-B14 WASHER-1/4X1/2IDX3OD 3
3-29 91-0810 BOLT-1/2 X 1-1/4 NF 3
3-30 64123-50 BOLT-HEX 3/8-16X1 1
3-31 64-799 WASHER-13/32 X 1-9/32 1
3-32 99-K39 BOLT-1/4 X 1-1/2 BH 2
(SN 1017 - )
3-33 453023 FLATWASHER, 1/4 4
(SN 1017 - )
3-34 64-688.7 SPACER 2
(SN 1017 - )
3-35 00-137 DECAL-SPIRAL INDICATOR 1
(SN 1017 - )
60-568.7 SUPPORT 1
(SN 1010 - )
3-36 56-059-17 TRIM-LOC-RUBBER 17" 1
(SN 1017 - )
3-37 06-010 CAP PLUG-1" 1
(SN 1017 - )
3-38 64-866 SHIM-SPINDLE 22 GA. 1
(1 PAIR OPTIONAL)
64-867 SHIM-SPINDLE 16 GA. 1
(1 PAIR OPTIONAL)
64-868 SHIM-SPINDLE 12 GA. 1
(1 PAIR OPTIONAL)
3-39 47-090 LATCH-RUBBER 3" LONG 3
(SN 1838 - )
3-40 04-007 POP RIVET, 1/8 X 1/4 SS 6
(SN 1838 - )
3-41 64123-15 BOLT-3/8-16 X 3/4 3
3-42 64025-05 NUT-3/8-16 3
3-43 64006-03 LOCKWASHER-3/8 3
