ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
FIGURE 5
FRAME PARTS 60"
5-1 64141-4 NUT-WLF 3/8-16 10
5-2 03-0610 CLEVIS PIN-3/8 X 1-1/4 1
5-3 02-PP0318 PRESTO PIN-3/32 X 2-5/16 1
5-4 29-010 GREASE FITTING-1/4 2
5-5 62-695 FRAME-TUBE 1
(SN 1001 - 1194)
62-726.7 FRAME-TUBE 1
(SN 1195 - )
5-6 64123-70 BOLT-HEX 3/8-16X1-1/2 3
5-7 53-060 HUB CAP-FOR MOWER 2
5-8 99-AC12NFLOCKNUT-CENTER 3/4 NF 2
5-9 64163-06 WASHER-.768/.756X1.25X14 12
5-10 55-Z9504AB BALL BEARING-3/4 ID 4
5-11 64-807 SPACER 2
(SN 1001 - 3246)
64-845 SHIELD-BEARING 2
(SN 3247 - )
5-12 4132783.7 CASTER, MOWER 2
5-13 90-0640 BOLT,3/8-16 X 5 2
5-14 53-104 WHEEL-10.25X3.25 CASTER 2
(SN 1001 - 6813)
55-G527 BRG-BALL F/53-104 WHL 2
55-107 BEARING-5/8 ID X 1-3/8 OD 2
OPT HD)
53-186 WHEEL-10.25X3.25 CASTER 2
(SN 6814 - )
55-112 BRG-ROLLER 5/8 ID X 1-3/8 1
53-187 RETAINER-FLANGED 2
5-15 64163-16 WASHER-41/64X1, 3/8X12GA12
5-16 50-062 AXLE TUBE-CASTER WHL 2
5-17 64-799 WASHER-13/32 X 1-9/32 18
5-18 42-428 LINK-RIGHT 1
(SN 1001 - 1194)
42-444.7 LINK-RIGHT 1
(SN 1195 - )
5-19 64123-16 BLT-HEX 3/8-16X1-1/4 3
5-20 64229-05 LOCKNUT, 1/2-13 NYLON 3
5-21 42-427 LINK-LEFT FRONT 1
(SN 1001 - 1194)
42-445.7 LINK-LEFT FRONT 1
(SN 1195 - )
5-22 42-430 LINK-HEIGHT ADJUST 1
(SN 1001 - 1194)
42-447.7 LINK-HEIGHT ADJUST 1
(SN 1195 - )
5-23 64123-117 BOLT-HEX 1/2-13X1-1/2 1
5-24 90-0832 BOLT-1/2 X 4 2
5-25 64163-67 WASHER-.516X1X12GA 2
5-26 42-429 LINK-MID LEFT 1
(SN 1001 - 1194)
42-446.7 LINK-MID LIFT 1
(SN 1195 - )
5-27 62-697 FRAME-ROLLER 1
(SN 1001 - 1194)
62-728 FRAME-REAR ROLLER 1
(SN 1195 - 5456 )
62-870.7 FRAME-REAR ROLLER 1
(SN 5457 - )
5-28 50-067 ROLLER-REAR 1
(SN 1001 - 1194)
50-079.7 ROLLER-REAR 1
(SN 1195 - )
5-29 50-105 ROLLER-FRONT 1
85-B11 BEARING-3/4" WOOD RLR 2
5-30 50-074 AXLE-ANTI SCALP ROLLER 1
5-31 64123-219 BOLT-HEX 3/8-16X6 1
5-32 64141-6 NUT, 5/16-18 4
5-33 55-FB16016 BEARING-160 FLANGE 1" 2
5-34 64018-15 BLT-CRG 5/16-18X1 4
(SN 1001 - 2010)
64123-47 BLT-HEX 5/16-18X1-1/4 4
(SN 2011 - 5456)
99-K62 BOLT-FLANGE 5/16 X 1-1/4 4
(SN 5457 - )
99-K62 BOLT-FLANGE 5/16 X 1-1/4 4
(SN 1578 - )
5-35 64-663 BUSHING-ADJ LINK THIN 6
(SN 1195 - )
5-36 64123-87 BOLT-HEX 3/8-16X1-3/4 1
5-37 29-045 GREASE FITTING-1/4 45 1
5-38 64-662 BUSHING-ADJ LINK THICK 2
(SN 1195 - )
5-39 64139-21 BLT-WLF 3/8-16X3/4 1
To Next Page
