31
ROTARY
MOWER
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HITCH & DRIVE PARTS
FIGURE 7
7-1 64164-11 KEY-3/16X3/16X1-1/4 SQ 2
7-2 64229-05 LOCKNUT, 1/2-13 NYLON 3
64141-13 NUT WLF 1/2-13 1
7-3 81-A128 BELT-48" 1
81-A158 BELT-60" 1
81-A180 BELT-72" 1
7-4 83-BK5012 PULLEY-5" 3/4" BORE 1
7-5 64139-24 BLT-WLF 3/8-16 X 1 4
7-6 64141-4 NUT-WLF 3/8-16 16
7-7 64-660.7 ANCHOR-LFT ARM RT 2
(USED ON 48" SN 1001 - 1493)
64-934.7 ANCHOR-LFT ARM RT 2
(USED ON 48" SN 1494 - )
64-646.7 ANCHOR-LFT ARM RT 2
(USED ON 60" SN 1001 - 4727)
64-936.7 ANCHOR-LFT ARM RT 2
(USED ON 60" SN 4728 - )
64-668.7 ANCHOR-LFT ARM RT 2
(USED ON 72" SN 1001 - 1969)
64-938.7 ANCHOR-LFT ARM RT 2
(USED ON 72" SN 1970 - )
7-8 99-K82 BOLT, FLANGE 1/2-13 X 2 1
7-9 64-661.7 ANCHOR-LFT ARM LFT 2
(USED ON 48" SN 1001 - 1493)
64-935.7 ANCHOR-LFT ARM LFT 2
(USED ON 48" SN 1494 - )
64-645.7 ANCHOR-LFT ARM LFT 2
(USED ON 60" SN 1001 - 4727)
64-937.7 ANCHOR-LFT ARM LFT 2
(USED ON 60" SN 4728 - )
64-669.7 ANCHOR-LFT ARM LFT 2
(USED ON 72" SN 1001 - 1969)
64-939.7 ANCHOR-LFT ARM LFT 2
(USED ON 72" SN 1970 - )
7-10 85-SC08 SET COLLAR-1/2" 2
7-11 62-698.7 HITCH ARM-RIGHT 1
62-858.7 HITCH ARM-RIGHT 1
7-12 64139-24 BLT-WLF 3/8-16 X 1 4
7-13 80-237 SHAFT-MOWER DRIVE 1
7-14 55-FB23012 BRG-2-BOLT FLANGE 3/4 2
7-15 62-699.7 HITCH ARM-LEFT 1
62-857.7 HITCH ARM-LEFT 1
7-16 64141-6 NUT, 5/16-18 2
7-17 64-611.7 SHIELD-DRIVE PULLEY 1
7-18 64139-08 BOLT-5/16-18X3/4 WLF 2
47-077 KNOB-SM CLMPNG W/STUD 1
7-19 64139-21 BLT-WLF 3/8-16X3/4 12
7-20 64229-05 LOCKNUT, 1/2-13 NYLON 1
7-21 83-BK4012 PULLEY-4" 3/4" BORE 1
(USED ON 72" ONLY)
83-BK5012 PULLEY-5" 3/4" BORE 1
(USED ON 60" & 72" MODELS ONLY)
7-22 64229-02 LOCKNUT-NYLON 5/16-18 1
7-23 64163-67 WASHER-.516X1X12 2
7-24 99-G06 WASHER-1/4 1
7-25 64123-54 BOLT, 5/16-18X3/4 HEX 1
7-26 64-933.7 LIFT ARM-TOP LINK 1
7-27 64-932.7 LIFT ARM-LOWER LINK 1
7-28 64141-13 NUT WLF 1/2-13 1
7-29 64006-05 LOCKWSHR-1/2 1
7-30 64123-125 BOLT-HEX 1/2-13X2-3/4 1
7-31 64268-03 NUT-FL NYLON LOCK 3/8-16 4
* 81-A040 BELT 1
* 81-B041 BELT 1
* NOT ILLUSTRATED
