Steiss 5 Series - Inflation of Mattress

4
INFLATION OF MATTRESS
1. Ensure that the Cardio Pulmonary Resuscitation (CPR) valve of side mattress is closed.
CAUTION: It is important to ensure that no person/object is lying/sitting on the mattress when it
is initially being
2.
maximum pressure.
NOTE: ‘MAX’ and ‘STATIC’ modes are designed to return to ‘dynamic mode’ after 30 minutes activation.
4
3.
4. When the mattress is fully inflated, the mattress is now ready to be used and patient can be placed
on to the air mattress. The pump is designed automatically default to Alternate mode with Automatic
Weight Detection enable. The system will automatically set to an optimum pressure for a patient’s
weight from 30 to 160Kg.
5. The
pump and mattress will then run continuously in ‘dynamic mode’.
