CONNECTIONS
FRONT
REAR ( F20 – F40 )
REF
DE
SCRIPTION
MIG
A
EURO CONNECTOR
MIG TORCH
B
CONNECTOR 14
WAY FRONT
( optional for F20 )
PUSH PULL//UP-DOWN
C
WATER COOLING
H
OT
TORCH COOLING ( FROM
THE TORCH)
D
WATER COOLING
COLD
TORCH COOLING (TO THE
TORCH)
REF
DESCRIPTION
M
IG
E
RS 232 MODBUS
-
F CONNECTOR 14
WAY
REAR
TO WELDING POWER
SOURCE
G
AUTOMATION KT
( optional )
H GAS INLET
TO WELDING POWER
SOURCE/GAS CYLINDER
L
DIN SOCKET REAR
“
MIG
”
TO WELDING POWER
SOURCE
M
WATER COOLING
HOT
TORCH COOLING (FROM THE
COOLER)
N
WATER COOLING
COLD
TORCH COOLING (TO THE
COOLER)
