FRONT CONNECTOR 14 WAY ‘C’: REMOTE CONTROL
FRONT CONNECTOR 14 WAY ‘C’: UP-DOWN TORCH
FRONT CONNECTOR 14 WAY ‘C’: PUSH PULL TORCH CONNECTION
C
ONN
ECT
OR
14 WAY
‘D’
PIN
DE
SCR
IPTION
TORCH TRIGGER
A
TORCH SWITCH
B
TORCH SWITCH
REMOTE CONTROL
E
REMOTE CONTROL CIRCUIT
COMMON
F
0 TO +5VDC INPUT REMOTE
CONTROL
G
+5VDC OUTPUT REMOTE CONTROL
D
+5VDC OUTPUT REMOTE
CONTROL.
I
SENSE 220K
J
SENSE 220K
GND
H
CHASSIS COMMON
CONNECTOR 14
WAY
‘D’
PIN
DESCRIP
TION
TORCH TRIGGER
A
TORCH SWITCH
B
TORCH SWITCH
UP/DOWN TORCH
E
REMOTE CONTROL CIRCUIT
COMMON
F
DOWN
G
UP-DOWN COMMU.
D
UP-DOWN COMMU.
C
UP
I
SENSE 1 JUMPER
J
SENSE 2 JUMPER
GND H CHASSIS COMMON
CONNECTOR 14 WAY
‘D’
PIN
DESCR
IPTION
TORCH TRIGGER
EUR
TORCH SWITCH EURO
CONNECTOR
EUR
TORCH SWITCH EURO
CONNECTOR
REMOTE CONTROL
E
REMOTE CONTROL CIRCUIT
COMMON
F
0 TO +5VDC INPUT REMOTE
CONTROL
G
+5VDC OUTPUT REMOTE CONTROL
D
+5VDC OUTPUT REMOTE CONTROL
I
SENSE 220K
J
SENSE 220K
GND
H
CHASSIS COMMON
PUSH PULL
M
+ MOTOR
N
-MOTOR
