Stenner Pumps 45M5 - Feed Rate Control; Feed Rate Control Exploded View

Classic Series www.stenner.com
42
FEED RATE CONTROL EXPLODED VIEW
Contact factory for part numbers.
FRC Screw A
Feed Rate
Mounting Plate
Dial Ring
Variable Cam
Index Pin Lifter
Index Pin Holder
Index Pin Spring
Index Pin
Index Spider
Index Plate
Feed Rate Housing
Main Shaft
Double Head/
Adjustable Output
Main Shaft Dual Head
Dual Control/
Adjustable Output
Main Shaft Single
Head/Adjustable
Output
Mounting Rivet
