Stephill SSD8500 - Engine Service; Alternator Service; 8 Kubota Consumable Spares; 9 General Spares

Issue 3
Page 10 18/06/2015
7.1 Engine service
Service the engine strictly in accordance with the instructions given in the relevant
operator manual / handbook. An approved specialist must carry out any maintenance.
Any spare parts required should be of genuine manufacturer’s origin. Note: failure to
adhere to manufacturer’s recommended service schedules may invalidate the warranty.
Please consult engine operator’s manual for full service intervals. For further information
please consult engine manufacturer’s website. www.kubota.co.uk
7.2 Alternator service
Brushless alternators employed on Stephill Generators are maintenance free. Service
must be carried out by competent qualified personnel strictly in accordance with the
instructions given in the handbook. Any spare parts required should be of genuine
manufacturer’s origin. For further information please consult alternator manufacturer’s
website. www.nsmgenerators.com and www.sogagroup.com
8 Kubota consumable spares
Description
D722
Z602
Oil filter
015-0004
015-0004
Fuel filter
015-0005
015-0005
In line fuel filter
015-0030
015-0030
Air filter
015-0003
015-0003
Fan belt
015-0007
015-0007
9 General spares
Part Number
Description
Qty
015-0001
Kubota D722 Engine
1
015-0150
Kubota Z602 Engine
1
015-0078
Kubota D722/Z602 Charge regulator
1
018-0054
50mm Grommet
1
028-0048
Alternator NSM M 112 SB/2 (SSD10000/S & SSD8500)
1
032-0016
Alternator SINCRO SK160 CA21 (SSD10000W)
1
032-0007
AVR Sincro BL4-U (SSD10000W)
1
018-0064
AVR RCM-2 (SSD10000)
1
037-0023
55mf Capacitor
1
037-0017
30mf Capacitor (SSD10000)
1
037-0020
40mf Capacitor (SSD10000)
1
024-0108
SSD10000 Silencer
1
024-0110
SSD10000 Kubota D722 Manifold pipe
1
024-0197
SSD8000 Kubota Z602 Manifold pipe
1
024-0111
SSD10000 Kubota D722 Down pipe
1
024-0118
Perspex cover (Perspex only)
1
024-0129
SSD10000 Fuel tank
1
024-0145
Kubota D722 Radiator
1
024-0173
Kubota D722 Radiator cowl
1
024-0146
Kubota D722 Radiator top hose
1
024-0147
Kubota D722 Radiator bottom hose
1
024-0154
SSD10000 Fuel tank filler hose
1
048-0008
Fuel cap
1
024-1007
Air hose
0.5M
024-1004
Fuel drain hose
1
024-1005
Oil drain hose
1
024-1018
Hinge CFG 30/60 Control panel
2
024-1002
Control panel lock
1
024-1001
D/C Paddle black (Slam)
2
