Stephill SSD8500 - Control Panel Spares; Trolley Spares

Issue 3
Page 11 18/06/2015
9 General spares
Part Number
Description
Qty
024-1003
Finger pull
1
024-1006
Fuel sender
1
027-0016
Mount Engine/Alternator M10
4
027-1017
Mount Radiator Bottom M10
2
027-0048
Mount Radiator M6 Top (SSD8500)
2
027-0003
Mount Radiator M8
1
027-0047
Mount Engine/Alternator M10 (SSD8500)
4
027-0048
Mount Radiator Bottom M10 (SSD8500)
2
023-1029
Hinge radiator flap
2
023-1019
Cam 28mm Radiator lock
1
023-1020
Insert slot 2 x 4 Radiator lock
1
023-1021
Housing Radiator lock
1
023-1023
Door seal
4M
014-1000
Door hinge M5
4
024-0154
SSD10000 Fuel tank filler hose
1
024-0152
SSD10000 Fuel tank feed pipe
1
024-0153
SSD10000 Door spacer
8
9.1 Control panel spares
Part Number
Description
Qty
045-0061
DEEP SEA 3110
1
036-0018
40A Circuit breaker
1
036-0028
40Amp RCD 30mA
1
036-0049
16A Re-set
2
036-0052
32A Re-set
3
036-0039
MCB Cover
1
036-0043
Reset button 1A TR11
1
036-0055
Reset button 2A TR11
1
056-0002
12V 4 Pin relay
3
053-0003
70A Pre-heat Relay
1
044-0001
110V 16A Socket
1
044-0002
220V 16A Socket
1
044-0003
110V 32A Socket
2
044-0004
220V 32A Socket
1
043-0007
4 Pole change over switch
1
045-0006
Starter button (Fuel pump prime)
1
055-0010
Fuel gauge 10-180 ohm
1
045-0018
Emergency stop button
1
045-0032
Contact block normally closed
1
9.2 Trolley Kit
Part Number
Description
Qty
024-0130
Axle
1
024-0132
Handle Trolley Frame
2
024-0133
Trolley Frame
1
024-1019
Roll Pin
2
024-1020
Compression Spring
2
027-0020
Wheel Pneumatic
2
