4-18
122994-513 Operator Manual Operating Instructions
4.11 Power Door
Operation
Power door is controlled by touch pads located on the control panel
(refer to Figure 3-2).
IMPORTANT: Keep chamber door closed between cycles and when
washer is not in use.
Press DOOR OPEN touch pad to automatically raise door to open
position.
Press DOOR CLOSE touch pad to automatically lower door to
closed position.
If unit is equipped with power double doors, a door-interlock safety
feature allows only one door to be opened at a time to avoid cross-
contamination.
Load door can be operated only from load side control panel, and
unload door can be operated only from unload side control panel.
Unload side door can be opened ONLY AFTER COMPLETION OF
A CYCLE. Load side door can be opened at any time with operator
following appropriate Safety Precautions.
WARNING – BURN HAZARD:
• Except for an emergency, do
not open door when cycle is
in progress. In an emer-
gency, first stop cycle by
pressing STOP/RESET touch
pad and wait for water flow to
stop. Wear appropriate Per-
sonal Protective Equipment
(PPE) whenever reaching
into chamber.
• After pressing STOP/RESET
touch pad, wait until water
flow stops before slowly
opening door. Hot water/
steam may be sprayed
through door opening if
door is opened too soon.
WARNING–
PERSONAL INJURY
HAZARD: Risk of pinch point
between door and upper
panel. Do not push on top
portion of doors; do not push
on door when door is rising;
do not push on door when
door is jammed.
