4. Assembling Instruction
Must check and make ensure that installed the“O”seal ring before
connect power supply.
This product only allow adult carry out assembly work and strictly
follow this operating stipulates.
1.Press the Fast Disassemble Button to remove the Head Cover.
2.Push the Battery into cabin according the shape of Battery
Compartment until the bottom.
3.Force to tightly insert after make the Fix Position Groove of power
supply joint outer wall on Main Unit corresponding to the Convex
Rib on internal wall of battery power supply joint.
4.Turn Tighten Nut clockwise until tightened.
5.Make the Head Cover align to slot of Main Unit, lightly squeeze
and send out “Ta” sound then means it tightly locked.
4.1 Install the Battery
1.Press the Fast Disassemble Button to remove the Head Cover.
2.Turn the Tighten Nut counterclockwise until loosened.
3.Plug out the main unit power supply joint from the battery’s.
4.Remove the Battery from the Compartment by draging the
Lanyard on the battery.
5.Make the Head Cover align to slot of Main Unit, lightly squeeze
and send out “Ta” sound then means it tightly locked.
4.2 Remove the Battery
Battery
Head Cover
Tighten Nut
Fast Disassemble
Button
“O”seal ring
Battery
Compartment
Main Unit
Lanyard
08
Main Unit power supply joint
Fix Position
Groove
Battery power supply joint
Convex Rib
Lanyard
To Next Page
