3-3-2 Description
No
Parts
Parts No.
Q’TY
Remark
1
Main frame assembly
-
1 ea
2
Tracking bush
300182
2 ea
3
Guide finger (LH / RH)
301690 / 301691
1 set
4
Deck
301689
1 ea
5
Running belt
301693
1 ea
6
Deck washer
300197
4 ea
7
Socket flat head
300127
4 ea
M8 x 30L
8
Rear roller assembly
301694
1 ea
9
Hexagon socket head
300102
2 ea
M12 x 120
10
Washer split lock
300031
2 ea
Ø12
11
Washer flat
300012
2 ea
Ø12
12
Front roller assembly
301695
1 ea
13
Poly V-belt
300203
1 ea
14
Hexagon socket head
300084
2 ea
M8 x 35L (SEMS)
15
Driving motor assembly
200043
1 ea
16
Motor insulation bush
300208
4 ea
17
Hexagon socket head
300082
4 ea
M8 x 20L (SEMS)
18
Motor limit bush
300209
2 ea
19
Auto tensioner assembly
201278
1 set
20
Hexagon socket head
300082
2 ea
M8 x 20L (SEMS)
21
Inverter
300228
1 ea
TM5
22
Machine pan head
300040
4 ea
M5 x 12L (SEMS)
23
Breaking resister
300224
1 ea
24
Machine pan head
300040
2 ea
M5 x 12L (SEMS)
25
Partition
301703
1 ea
26
Machine pan head
300040
1 ea
M5 x 12L (SEMS)
27
Non slip pad
301706
2 ea
28
Adapter bracket
300223
1 ea
29
Noise filter
300218
1 ea
30
Machine pan head
300040
2 ea
M5 x 12L (SEMS)
31
Adapter
301114
1 ea
12V
32
Adapter fix bracket
300222
1 ea
33
Machine pan head
300040
4 ea
M5 x 12L (SEMS)
34
Machine pan head
300040
2 ea
M5 x 12L (SEMS)
