3-15 Assembly Display Frame (#7)
3-15 Description
No Parts
Parts No. Q ’ TY Remark
1 Heart rate pipe assembly 32M1-TSA21 1 ea
2 Heart rate rubber 32M3-TST31 1 ea
3 Heart rate mold top 32M3-TS181 1 ea
4 Heart rate mold bottom 32M3-TS191 1 ea
5 Tapping pan head 33U5-6B410 2 ea Φ 4 x 10 L
6 HR sensor cell 32M1-TST31 2 ea
7 3M tape 32M1-TS3T1 2 ea
