www.stiebel-eltron.com DHE | 103
INSTALLATION
Specication
ENGLISH
DHE 18/21/24 DHE 27
Versions
Adjustable connected load X -
Temperature settings °C Off, 20-60 Off, 20-60
Protection class 1 1
Insulating block Plastic Plastic
Heating system heat generator Bare wire Bare wire
Cover and back panel Plastic Plastic
Colour White White
IP rating IP25 IP25
Dimensions
Height mm 466 466
Width mm 225 225
Depth mm 116 116
Weights
Weight kg 3.1 3.1
Note
The appliance conforms to IEC 61000-3-12.

STIEBEL ELTRON DHE 18 Specifications

General

Type	Instantaneous Water Heater
Power Output	18 kW
Voltage	400 V
Control	Electronic
Protection Class	IP25
Installation	Wall-mounted
Dimensions (H x W x D)	478 x 225 x 105 mm
Phases	3/PE
Frequency	50/60 Hz
Specific water volume at Δt 30 K	8.6 l/min
Specific water volume at Δt 35 K	7.4 l/min
Specific water volume at Δt 25 K	10.3 l/min
Energy efficiency class	A
Application	Domestic
