INSTALLATION
Commissioning
82 | DHE www.stiebel-eltron.com
Changing the connected load via jumper slot; only with
DHE18/21/24
If you select a connected load other than the 21kW factory setting
for appliances with selectable connected load, you will need to
reposition the jumper.
1
2
3
D0000089187
Install the jumper in the required position on the pin strip.
Jumper position Connected load
1 18kW
2 21kW
3 24kW
No jumper 18kW
11.2 Initial start-up
≥ 60 s
D0000053277
Open and close all connected draw-off valves several times,
until all air has been purged from the pipework and the
appliance.
Carry out a tightness check.
D0000053278
Activate the safety switch by firmly pressing the reset button
(the appliance is delivered with the safety switch disabled).

Table of Contents

Other manuals for STIEBEL ELTRON DHE 18

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the STIEBEL ELTRON DHE 18 and is the answer not in the manual?

STIEBEL ELTRON DHE 18 Specifications

General IconGeneral
TypeInstantaneous Water Heater
Power Output18 kW
Voltage400 V
ControlElectronic
Protection ClassIP25
InstallationWall-mounted
Dimensions (H x W x D)478 x 225 x 105 mm
Phases3/PE
Frequency50/60 Hz
Specific water volume at Δt 30 K8.6 l/min
Specific water volume at Δt 35 K7.4 l/min
Specific water volume at Δt 25 K10.3 l/min
Energy efficiency classA
ApplicationDomestic
