STIEBEL ELTRON WPL E Series - Page 33

INSTALLATION
Specication
34 | WPL E | WPL cool www.stiebel-eltron.com
Cooling capacity diagram WPL 18 cool
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
5 10 15 20 25
Außentemperatur 30 °C
Außentemperatur 35 °C
Flow temperature °C
Power consumption P
(el)
/ kW Cooling capacity Q'
(H)
/ kW
Coefficient of performance e / -
Flow temperature °C
1,5
2
2,5
3
3,5
4
5 10 15 20 25
26_03_01_0968
26_03_01_0969
Outside temperature 30 °C
Outside temperature 35 °C
