INSTALLATION
Safety
www.stiebel-eltron.com WPL E | WPL cool | 7
INSTALLATION
7. Safety
Only a qualified contractor should carry out installation, commis-
sioning, maintenance and repair of the appliance.
7.1 General safety instructions
We guarantee trouble-free function and operational reliability only
if original accessories and spare parts intended for the appliance
are used.
7.2 Instructions, standards and regulations
Note
Observe all applicable national and regional regulations
and instructions.
7.3 Operation of the appliance in buildings with
combustion equipment
As the appliance can produce negative pressure in the installation
room, we recommend using a tightly sealing door between the
installation room and the living space for operation with com-
bustion equipment.
If, due to its use, the installation room is connected to the ex-
tract air system, you must also allow for a supply air valve in the
installation room in this particular case to prevent any further
increase in the negative pressure in the installation room. The
negative pressure created by the appliance in the installation room
is heavily influenced by the pressure drop in the outdoor air line.
For this reason, the outdoor air line in particular should be as
short as possible.
8. Appliance description
For outdoor installation the appliance offers additional frost pro-
tection of the heating water pipes. The integral frost protection
circuit starts the heating circulation pump in the heat pump circuit
automatically at +8°C condenser temperature, and in doing so
ensures circulation in all water-filled sections.
The heat pump starts automatically when the temperature in the
heat pump circuit drops below +5°C.
8.1 Standard delivery
The casing components for the appliance are delivered in a sep-
arate packing unit.
8.1.1 Standard appliance
- Type plate
8.1.2 Casing components – outdoor installation
- Hood – outdoor installation
- Front panel
- Back panel
- Pipe bend for heating circuit flow
- Pipe bend for heating circuit return
8.1.3 Casing components for indoor installation
- Cover - indoor installation
- Front panel
- Back panel
- Pipe bend for heating circuit return
8.2 Required accessories
8.2.1 Outdoor installation
- WPM3 heat pump manager
- Accessories – outdoor installation
- Pressure hoses SD25 or SD32
8.2.2 Indoor installation
- WPM3 heat pump manager
- Accessories – indoor installation
- Pressure hoses SD25 or SD32
8.2.3 Cooling
- Remote control for heating systems FEK
8.3 Additional accessories
8.3.1 Outdoor installation
- Remote control for FE7 heating systems
- Water softening fitting HZEA
- SP cool distributor strip
- Internet Service Gateway ISG
8.3.2 Indoor installation
- Air hose DN 560 x 4 m
- Hose connection panel 560
- Wall outlet AWG 560 H-SR
- Wall outlet AWG 560 H-GL
- Wall outlet AWG 560 V-SR
- Wall outlet AWG 560 V-GL
- Wall outlet AWG 560 L
- Wall outlet AWG 600 L
- Remote control for FE7 heating systems
- Condensate pump PK 10
- Water softening fitting HZEA
- SP cool distributor strip
- Internet Service Gateway ISG
