32
User’s manual
EN
PART REPLACEMENT
RECOMMENDATIONS FOR REPLACING PARTS
Important
Replace and repair any parts according to the manufacturer’s instructions, or contact the service centre if
these operations are not included in the manual.
BATTERY REPLACEMENT
Important
Replace the batteries at an authorised service centre.
BLADE REPLACEMENT
1. Stop the robot safely (see “Robot Safety Stop”).
Important
Use protective gloves to prevent injuries to your hands.
For replacement, use only the original blade suitable for the device.
MODEL
Autoclip M3 Autoclip M5
Cutting blade code
122104113/0 122104111/0
2. Turn the robot over and position it so as not to ruin the covering
hood.
3. Unscrew the screws (B) to remove the blade (A).
4. Insert a new blade and fasten the screws.
5. Turn the robot back over to its operating position.
