6
User’s manual
EN
TECHNICAL INFORMATION
TECHNICAL SPECIFICATIONS
Description
Model
Autoclip M3 Autoclip M5
8030M30 8030M50
Maximum recommended surface that can be mowed
Working capacity ( -20%(*)) m
2
(sq ') 300 (3228 ') 500 (5380 ')
Features
Dimensions (W x H x D) mm 537x415x252
Robot weight (incl. battery) kg 9,5
Cutting height (Min-Max) mm (") 25-60 (0,98-2,36 ")
Diameter of blade mm (") 220 (8,66 ") 250 (9,84 ")
Motors with brushes
Cutting blade speed RPM 2400
Ground speed Metres / Minute 25 (82 ')
Maximum recommended slope
managed (*)
%
45% allowable, based on the lawn conditions and accessories
installed.
35% maximum managed and recommended in conditions of a
trimmed lawn.
20% in proximity of the outside edge or perimeter wire
Ambient operating temperature Max °C
ROBOT: -10°(14 F.) (Min) +50° (122 F.) (Max)
CHARGING STATION: -10°(14 F.) (Min) +45° (113 F.) (Max)
BATTERY CHARGER: -10°(14 F.) (Min) +40° (104 F.) (Max)
Measured sound power level dB(A) 57
Water protection class IP
ROBOT: IPx4
CHARGING STATION: IPx4
BATTERY CHARGER: IPx4
Electrical features
Power supply unit (for lithium battery)
Mean Well
OWA-60E-30ZCT
Input:
100 - 240 V~; 1.2 A;
50/60 Hz; Class 2
Output: 29.4 V
; 2.0 A;
Type of accumulator and charging batteries
Rechargeable Lithium-Ion Battery
(rated voltage)
25.9V – 1x2.5 Ah
Battery charger 29.4 Vcc - 2.0 A
Average recharging time hh:mm 1:15
Average mowing duration after a full
charge cycle (*)
hh:mm 0:50
(*) Depends on the condition of the grass, lawn and the complexity of the mowing area.
