13
User’s manual
EN
Marking the boundary of the work area
3. Check the entire lawn surface and assess whether it is
necessary to divide it into separate work areas as per the
rules described here below. Before installing the perimeter
wire, check the entire path to make this procedure easier. The
illustration shows a lawn with the track for installation of the
perimeter wire.
During installation, identify any secondary areas. A secondary
area is part of a lawn connected to the primary lawn with
a passage that is difcult to reach by the robot's normal
movement. The area must be reachable without any rises
or drops greater than those allowed. Whether a zone is to
be dened a “secondary area” also depends on the size of
the primary area. The larger the primary area, the harder it
will be to reach narrow passages. More generally, a passage
narrower than 200 cm (78.74 ") is considered a secondary area.
The number of secondary areas managed depends on the
characteristics of the model (See “Technical Specications”).
The minimum passage allowed is 70 cm (27.56 ") from each
edge of the perimeter wire. The perimeter wire must be
positioned at a distance of (to be indicated below) from any
objects outside the lawn; therefore, the necessary space for
passing must be 140 cm (55.12 ") if there is a wall or hedge
on both sides.
If this passage is very long, the width should be more than
70
cm
(27.56 ") between perimeter wires.
During programming, it is necessary to congure the size of the
secondary areas as a percentage of the lawn, and the quickest
direction for reaching it (clockwise or counter-clockwise), as
well as the number of meters of wire needed to reach the
secondary area. See “Programming Mode.”
Track for laying
the perimeter wire
min. 70 cm / 27,56 "min. 70 cm / 27,56 "
min. 70 cm / 27,56 "
corridor with a minimum passage
of 70 cm / 27,56 " from edge to edge.
PRIMARY AREA
SECONDARY AREA
