72
ENGLISH
EN
Original instructions for use
5.13 LUBRICATION
All lubrication points in accordance with the table
below must be lubricated every 50 hours of opera-
tion as well as after every wash.
5.14 FUSES
If any of the faults listed below occurs, replace the
relevant fuse. See fig. 19.
6 PATENT - DESIGN
REGISTRATION
This machine or parts thereof is covered by the fol-
lowing patent and design registration:
SE9901091-0, SE9901730-3, SE9401745-6,
US595 7497, FR772384, DE69520215.4,
GB772384, SE0301072-5, SE04/000239 (PCT),
SE0401554-1.
GGP reserves the right to make alterations to the
product without prior notification.
Object Action Fig.
Wheel
bearing
2 grease nipples.
Use a grease gun filled with univer-
sal grease. Pump until the grease
emerges.
27
Centre
point
4 grease nipples.
Use a grease gun filled with univer-
sal grease. Pump until the grease
emerges.
28
Steer-
ing
chains
Brush the chains clean with a wire
brush.
Lubricate with universal chain spray.
-
Ten-
sioning
arms
Lubricate the bearing points with an
oil can when each control is acti-
vated.
Ideally carried out by two people.
29
Control
cables
Lubricate the cable ends with an oil
can when each control is activated.
Must be carried out by two people.
30
Fault Fuse
The engine does not start or starts and
stops immediately. The battery is charged.
10 A
Sand spreader and electrical cutting height
adjustment do not work.
20 A
All electrical functions are out of opera-
tion. The battery is charged.
30 A
