10EN
In order for them to work properly, the anti-chip-
ping wheels (1) must be repositioned in the hole
which is most suited for the type of ground
(
5.4.5).
3.7 MOUNTING THE FRONT BUMPER
(if provided)
• Type “I” Bumpers
Mount the front bumper (1) on the bottom of the
frame (2) using the four screws (3).
• Type “II” Bumpers
Fit the two brackets, (1) and (2), on the bottom of
the frame (3) tightening down the screws (4).
Attach the front bumper (5) to the brackets, (1)
and (2), with the screws (6) and the nuts (7).
1
3
3
2
