31EN
3. INSTALLATION
9. Secure the charging base (L) to the ground with the xing screws (M).
10. Reposition the cover (C).
11. Connect the power supply plug to the electrical outlet.
12. When the robot lawn mower is not in the charging base, make sure that the indicator light on the
charging base (N ) is lit with a xed light. (see Par. 4.4).
WARNING:
The power supply cable and the power supply must remain outside the cutting
area.
3.6. CHARGING THE ROBOT LAWN MOWER AFTER INSTALLATION
Requirements and obligations:
• Charging base
Procedure:
1. Recharge the robot lawn mower (see Par. 4.4).
NOTE: When charged for the rst time, the batteries must remain connected for at least 2 hours.
M NC
L
