WORKSHOP MANUAL
T...102/122 - TC...102/122
Map of functional units
Dismantle the front wheel.
The front wheel bearings (1) are force splined into the
front wheel hub.
A 10 - 12 mm diameter round bar (2) must be used to
extract a bearing, inserted from the opposite side and
struck with a hammer around various points of the in-
ner circumference of the bearing.
The new bearing must be tted with the help of a pla-
stic mallet or of a bronze pad (3) that only acts on the
bearing’s outer ring.
Validity
General informations
Related topics
[
2.2] Tools
[
2.3] Lifting of the machine
[
6.1] Replacement of tyres and wheels
REPLACEMENT OF FRONT WHEEL BEARINGS
CHAPTER REVISION FROM ... PAGE
6.2 0 2018 1 of 1
