WORKSHOP MANUAL
TC 108 SD - TC 118 SD
Remove the central guard (17) xed by the screw (18).
The wheel cover (19) is xed by two screws (20) lo-
cated under the side footboards and two rear screws
(21).
On reassembly, ensure that the two side tabs (22) of
the cover are correctly inserted into the housings in
the footboards.
Complete the assembly process, follow the steps de-
scribed above in the reverse order.
REMOVAL OF THE WHEEL COVER
CHAPTER REVISION FROM ... PAGE
5.2 1 2018 2 of 2
