Stiga TC 108 SD - Carburettor Solenoid Valve Operation Check

WORKSHOP MANUAL
Map of functional units
TC 108 SD - TC 118 SD
Connector CN1 must be connected to make this
check.
When the key is set to «ON», a click must be heard
from the carburettor solenoid valve coil.
General informations

Related topics
---
CARBURETTOR SOLENOID VALVE
OPERATION CHECK
CHAPTER REVISION FROM ... PAGE
7.5 0 2018 1 of 1
