WORKSHOP MANUAL
TC 108 SD - TC 118 SD
INDEX OF FUNCTIONAL UNITS
Transmission - Brake - Wheels
General informations
The use of outsourced thirdparty hydrostatic
drive units is foreseen on this machine.
This manual only describes the operations relat
ing to the application of the machine units; refer
ence to the drive unit’s Manufacturer’s Manual is
recommended for information regarding servic
ing, disassembly and replacement of compo
nents.
Related topics
[
1.1] Identication of components
RELATED TOPICS:
Adjustments and tuning
Brake adjustment ............................................................................. [
4.2]
Drive belt adjustment ........................................................................ [
4.3]
Drive pedal adjustment .................................................................... [
4.4]
Removal of external parts and main assemblies
Removal of the rear axle .................................................................. [
5.5]
Repairs
Replacement of tyres and wheels .................................................... [
6.1]
Replacement of front wheel bearings .............................................. [
6.2]
Replacement of the drive belt .......................................................... [
6.4]
