WORKSHOP MANUAL
TC 108 SD - TC 118 SD
Repeat the above operations in reverse for re as sem-
bly.
Check that the spacers (15 - 16 - 17 - 18) are correctly
tted to the shafts, in the sequence given.
Reattach all the connections, and then …
Check the brake.
Ret the rear wheels.
Ret the rear tank (if installed)
Ret the rear part of the wheel cover
If the the drive control rod has been replaced or com-
pletely pulled down:
Adjust the travel and the position of “neutral” for
the pedal
REMOVAL OF THE REAR AXLE
(Tu Torq K46F)
CHAPTER REVISION FROM ... PAGE
5.5 0 2018 2 of 2

  
