WORKSHOP MANUAL
TC 108 SD - TC 118 SD
Loosen the nut (7) almost completely, without remov-
ing the idler pulley (8) in order to be able to extract the
belt (5).
At this point the belt (5) is completely free and can be
extracted.
During reassembly operations, make sure the belt is
positioned accurately in relation to the containment
pins.
On completing the reassembly, it is necessary to ...
Adjust the blade engagement.
Always reassemble the internal (3-4) and
external (1-2) side safety guards.
CHAPTER REVISION FROM ... PAGE
6.5 0 2018 2 of 2
REPLACEMENT OF THE BLADES
CONTROL BELT
