STIHL 064, 066 81
Top:
Top: Round head screw on control lever spindle
Removing sleeve from stub Top:
(carburetor with compensator) End cover fastening screws Bottom:
(carburetor without compensator) 1 = Spindle
Bottom: 2 = Inlet control lever
End cover fastening screws Bottom: 3 = Helical spring
(
carburetor with com
p
ensator
)
Se
p
aratin
g
g
asket and dia
p
hra
g
m 4 = Inlet needle
- Pull the sleeve off the compen- - On carburetors without compen- - The inlet needle valve is located
sator's stub. sator, unscrew the metering in a recess in the metering dia-
chamber end cover and lift it phragm chamber. Take out the
- To disassemble the carburetor, away. round head retaining screw.
take out the screws of the meter-
ing chamber end cover with com- - Remove the metering diaphragm - Remove the inlet control lever
pensator and lift away the cover. and gasket from the carburetor with spindle, helical spring and
body or the cover and separate inlet needle.
them carefully.
- Inspect the metering diaphragm
and gasket and replace if necess-
ary.
