STIHL 064, 066 92
12. Special Servicing Tools and Aids
12.1 Special Servicing Tools
No. Part Name Part No. Application
1 Locking strip 0000 893 5902 Blocking crankshaft
2 Press sleeve 1119 893 2401 Fitting oil seal (clutch side)
3 Press sleeve 1128 890 3900 Fitting oil seal (ignition side)
4 Assembly sleeve 1122 893 4600 Protects oil seal at clutch side
5 Puller 0000 890 4400 Removing oil seals
6 - Jaws (No. 6) 0000 893 3711
7 Puller 1110 890 4500 Removing flywheel
8 Crimping tool 5910 890 8210 Attaching connectors to electric wires
9 Assembly drift 1108 893 4700 Fitting piston pin
10 Clamping strap 0000 893 2600 Compressing piston rings
11 Wooden assembly block 1108 893 4800 Fitting piston
12 Carburetor and crankcase 1106 850 2905 Testing carburetor and crankcase
tester for leaks
13 Vacuum pump 0000 850 3500 Testing crankcase for leaks
14 - Nipple 0000 855 9200
15 - Fuel line 1110 141 8600
16 Sealing plate 0000 855 8106 Sealing exhaust port for leakage test
17 Test flange 1113 850 4200 For leakage test
18 Setting gauge 1111 890 6400 Setting air gap between
ignition module and flywheel
19 Socket, 13 mm 5910 893 5608 Crankshaft nut
20 Socket, 19 mm 5910 893 5612
21 Torque wrench 5910 890 0300
22 Torque wrench 5910 890 0310
23 Screwdriver bit I-5x150 0812 542 2104 For spline screws
24 Assembly hook 5910 893 8800 Removing pickup bodies
25 Installing tool 5910 890 2212 Fitting hookless snap rings in piston
26 Press arbor 1122 893 7200 Removing crankshaft bearing
at ignition side
27 Press arbor 1119 893 7200 Removing and installing crankshaft
bearings
28 Assembly hook 5910 890 2800 Detaching springs from clutch shoes
29 Installing tool 0000 890 2201 Flaring rope guide bush
30 Assembly tube 1117 890 0900 Attaching the brake spring
31 Centering tool 1118 893 3500 Centering heating generator
32 Service tool AS 5910 007 2205 Removing crankshaft (clutch side)
33 Service tool ZS 5910 007 2220 Removing crankshaft (ignition side)
34 T-handle screwdriver 5910 890 2400 For all IS screws
QI-5 x 150
35 Stud puller MS 5910 893 0501 Removing bar mounting studs
36 Puller 1107 890 4500 Removing generator centering tool
37 Press disk 5910 893 5100 Installing rewind spring
