BF
English
17
1 Drive Tube
2 Deflector
3 Outer Right-Hand Cultivator Blade
4 Inner Right-Hand Cultivator Blade
5 Inner Left-Hand Cultivator Blade
6 Outer Left-Hand Cultivator Blade
7 Hitch Pin
Main Parts
3
4
5
6
7
1
2
504BA019 KN
