Definitions
1 Drive Tube
Encloses and protects the drive
shaft between the engine and
gearbox.
2 Deflector
Designed to reduce the risk of injury
from foreign objects flung
backwards toward the operator by
the attachments and from contact
with the attachments.
3 Outer Right-Hand Cultivator Blade
Metal blade, star-shaped with
pointed or curved tines. Mounts to
the outer right-hand side.
4 Inner Right-Hand Cultivator Blade
Metal blade, star-shaped with
pointed or curved tines. Mounts to
the inner right-hand side.
5 Inner Left-Hand Cultivator Blade
Metal blade, star-shaped with
pointed or curved tines. Mounts to
the inner left-hand side.
6 Outer Left-Hand Cultivator Blade
Metal blade, star-shaped with
pointed or curved tines. Mounts to
the outer left-hand side.
7Hitch Pin
Secures the attachments and
simplifies removal and installation of
the attachments.
Gearbox
Single-stage worm gear
Attachment
Weight
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers.
Warranty claims following repairs can be
accepted only if the repair has been
performed by an authorized STIHL
servicing dealer using genuine STIHL
replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
Specifications
Gear ratio: 44:1
Four rotor blades, double-edged, rotate
in same direction
Diameter: 230 mm (9.1 in)
Working width: 220 mm (8.7 in)
Attachment com-
plete with deflector 3.6 kg (7.9 lbs)
