18 BGA 85
7.8 Retaining Latch
Removing
– Remove the adapter, b 9.5
: Take the retaining latch (1) out of
the left half of the housing.
– Inspect the retaining latch and
replace if necessary.
Installing
: Fit the retaining latch (1) in the
left half of the housing.
The retaining latch (1) fits in or on
the guides (arrows) in the handle
housing.
– Reassemble all other parts in the
reverse sequence.
3905RA033 BL
1
