Stihl BT 120 C - Specifications; Definitions of Parts and Controls; Engine and Ignition Specifications

27BT 120 C
English / USA
1= Starter Grip
2= Carburetor Adjusting Screws
3= Air Filter Cover
4= Fuel Filler Cap
5= Muffler
(with spark arresting screen)
6= Slide Control
7= Throttle Trigger Interlock
8= Throttle Trigger
9= Spark Plug Boot
10= Screw Plug
11= Drilling spindle
12= Fuel Pump
13= Choke Knob
14= Auger Brake Activating Lever
15= Padding
Parts and Controls
2
3
427BA017 KN
1
4
5
6
7
15
14
13
12
11
10
9
427BA011 KN
8
