38 BT 130
Check the flywheel:
– Have pole shoes turned blue?
– Install new flywheel if necessary
Air gap:
– Check ignition module/flywheel,
and reset if necessary
Check the ignition lead:
– Severe chafing?
– Spark plug boot: Holes/cracks?
– Resistance: spark plug boot to ground:
spec. 1.5 – 12 kΩ
– Check resistance of ignition lead (spark plug
boot and ignition module removed):
spec.< 10 Ω,
If necessary, install new spark plug boot and/or
new ignition module
Check short circuit wire:
– Wire damaged?
– Connectors firmly seated?
– Check continuity, replace throttle cable if
necessary, b 8.1
1
3
yes
no
2
Ignition spark?
