12. Special Servicing Tools
New Special Tools
Existing Special Tools
No. Part Name Part No. Application Rem.
1 Screwdriver T27x15x75 0812 370 1004 Removing spline socket head screws 1)
No. Part Name Part No. Application Rem.
1 Pliers DIN 5254 - A10 0811 611 8200 Removing and installing circlips
2 Pliers DIN 5256 - C19 0811 641 8380 Removing and installing circlips
3 Screwdriver bit, T 27 x 125 0812 542 2104 Removing and installing spline socket
screws with electric or pneumatic
screwdrivers; tightening down screws
with torque wrench
4 Press sleeve 1115 893 4600 Installing hot ball bearing (gearbox
cover / clutch housing), installing cold
clutch drum
5 Assembly tool 1117 890 0900 Removing and instaling auger brake
spring
6 Press arbor 1117 893 7200 Removing and installing hot ball
bearing (clutch drum, gearbox housing,
gearbox cover),
oil seal, gearbox cover / ball bearing
7 Press sleeve 4112 893 2401 Installing oil seal
(ignition side / starter side)
8 Setting gauge 4118 890 6401 Adjusting air gap between the ignition
module and flywheel
9 Press arbor 4119 893 7200 Removing hot ball bearing (gearbox
housing and gearbox cover),
installing hot ball bearing (clutch
housing / clutch drum)
10 Locking screw 4282 890 2700 Blocking the crankshaft
11 Torque wrench 5910 890 0302 0.5 to 18 Nm
12 Torque wrench 5910 890 0312 6 to 80 Nm
13 Stud puller M5 5910 893 0510 Removing collar studs
Remarks:
1) Use for releasing only.
