4 BT 130
2. Specifications
2.1 Engine
BT 130
Displacement: 36.3 cc
Bore: 43.0 mm
Stroke: 25.0 mm
Engine power to ISO 8893: 1.4 kW
at 8,500 rpm
Cut-off speed (rated):
without auger
9,500 rpm
Idle speed (rated): 2,800 rpm
Clutch: Centrifugal clutch without linings
Clutch engages at (rated): 4000 rpm
Crankcase leakage test
at gauge pressure: 0.5 bar
under vacuum: 0.5 bar
Valve clearance
Inlet valve / exhaust valve 0.10 mm
2.2 Fuel System
Carburetor leakage test at gauge
pressure: 0.8 bar
Operation of tank vent at gauge
pressure: 0.5 bar
Fuel: as specified in instruction manual
2.3 Ignition System
Air gap between the ignition module
and flywheel: 0.25 (+ 0.05/- 0.10) mm
Spark plug (resistor type): NGK CMR 6 H
Electrode gap: 0.5 mm
2.4 Gearbox
Gear lubricant capacity: Clutch housing
Gearbox housing
Gearbox / clutch housing (total)
80 - 90 g, STIHL gear lubricant
80 - 90 g, STIHL gear lubricant
170 g, STIHL gear lubricant
