FS 111, FS 111 R
English
40
WARNING
To reduce the risk of fire and burn injury,
use only spark plugs authorized by
STIHL. Always press the spark plug
boot (1) snugly onto the spark plug
terminal (2).
Do not use a spark plug with a
detachable SAE adapter terminal (3).
Arcing may occur that could ignite
combustible fumes and cause a fire.
This can result in serious injuries or
damage to property.
N Only use resistor type spark plugs
with solid, non-threaded terminals
Installing the Spark Plug
N Screw the spark plug (3) into the
cylinder.
N Tighten down the spark plug (3) with
the combination wrench.
N Press the boot (2) firmly onto the
spark plug.
N Fit the cover (1) and screw it down
firmly.
If engine running behavior is
unsatisfactory even though the air filter
is clean and the carburetor is properly
adjusted, the cause may be the muffler.
Have the muffler checked for
contamination (carbonization) by your
servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer.
2
1
0000-GXX-1831-A0
3
Engine Running Behavior

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl FS 111 R and is the answer not in the manual?

Stihl FS 111 R Specifications

General IconGeneral
Engine Displacement31.4 cc
Power Output1.05 kW
Cutting Width420 mm
Sound Power Level107 dB(A)
Engine Power1.4 bhp
Shaft TypeStraight
Vibration DampingYes
Anti-Vibration SystemYes
Overall Length180 cm
Fuel Capacity0.71 l
Fuel Tank Capacity0.71 l
