Stihl FS 111 User Manual

FS 111, FS 111 R
English
46
1 Fuel Filler Cap
2 Carburetor Adjusting Screws
3 Starter Grip
4 Manual Fuel Pump
5 Cover
6 Muffler with Spark Arresting Screen
7 Machine Support
8 Throttle Trigger
9 Stop Switch
10 Throttle Trigger Lockout
11 Bike Handle
12 Handle Support
13 Wing Screw
14 Throttle Cable Retainer
15 Carrying Ring
16 Choke Knob
17 Air Filter Cover
18 Fuel Tank
19 Loop Handle
20 Barrier Bar
21 Drive Tube
# Serial Number
Main Parts
3
2
10
9
10
8
9
11
13
12
14
0000-GXX-0514-A0
15
20
19
15
8
1
4
5
6
#
7
16
17
18
14
21
21

Stihl FS 111 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	1.45 hp
Product color	Black, Metallic, Orange
Number of strokes	4
Sound power level	108 dB
Fuel tank capacity	0.71 L
Vibration emission	5.3 m/s²
Engine displacement	31.4 cm³
Sound pressure level	96 dB
Cutting diameter (max)	- mm
Power source	Gasoline

Weight and Dimensions

Length	1800 mm
Weight	5800 g
