FS 260 C, FS 360 C
English
22
Keep the information sheet for the
mowing head in a safe place.
Removing the mowing head
N Block the shaft
N Unscrew the mowing head
clockwise
Feeding out mowing line
A detailed description is contained in the
information sheet for the respective
mowing head.
SuperCut Mowing Head
Line is fed out automatically during
mowing and shortened to optimum
length by the blade on the deflector. Line
is fed out only if both ends of the line are
still at least 6 cm long.
AutoCut Mowing Head
N Hold the machine over an area of
lawn with the engine running
(mowing head must rotate)
N Tap the mowing head on the ground
– line is fed out automatically and
shortened to optimum length by the
blade on the deflector
Line is fed out only if both ends of the
line are still at least 2.5 cm long.
TrimCut Mowing Head
N Pull up the spool housing – turn
counterclockwise – approx. 1/6 turn
– until it engages – and then allow it
to spring back
N Pull the ends of the line outward
Repeat operation as needed until both
ends of the line are approx. 13 cm long.
A rotary movement from one click to the
next releases approx. 4 cm of line.
PolyCut Mowing Head
Proceed as described in the mowing
head information sheet.
Attaching grass cutting blades,
brush knives
With the grass cutting blade 255-8 (1),
the cutting edges must face clockwise.
Cutting attachments with 3 or
4 blades (2, 3) can face in any direction
– turn over these cutting attachments
periodically to avoid uneven wear.
N Use the guard ring for mowing tools
N Attach the deflector for metal
mowing tools
Remove the tool used to block the
shaft.
Always switch off the engine to
fed out mowing line by hand –
otherwise there is a risk of injury!
Always switch off the engine to
load the mowing head by hand –
otherwise there is a risk of injury!
