33Series 4144 Powerhead
7.6 Ignition System Troubleshooting
Engine does not run
Knob on carburetor:
– in position "F"?
Check the spark plug:
– Smeared with oil, black?
– Sooted?
– Electrode gap correct?
– Contacts shorted?
– Clean, readjust or replace the plug,
b 7.3
Check the spark plug boot:
– Firmly seated on plug (leg spring)?
– Leg spring hook in center of ignition lead?
– Boot damaged?
– If necessary, install new spark plug boot and/
or leg spring,
b 7.4
Test ignition system:
with ZAT 3 or ZAT 4
(use ZAT 3 as main spark gap
see TI 32.94),
b 7.3
1
Troubleshooting can be performed with the engine installed. Refer to service manuals of "Series 4144 Powerhead"
or "Series 4144 Components – FS, FC, KM" for descriptions of procedures.
