36 Series 4144 Powerhead
8. Special Servicing Tools
New Special Tools
Existing Special Tools
No. Part Name Part No. Application Rem.
1 Test flange 5910 850 4200 Crankcase leakage test
2 Sleeve (with 20° chamfer) 5910 893 1708 for intstalling tool 8
3 Puller 5910 893 0800 Removing flywheel
No. Part Name Part No. Application Rem.
1 Locking strip 0000 893 5904 Blocking the piston
2 Carburetor and engine tester 0000 850 1300 Testing engine and carburetor for leaks
3 Puller 5910 890 4501 Removing limiter caps
4 Screwdriver 5910 890 2305 Adjusting carburetor with limiter cap
- Setting disk 5910 893 6600 Add-on for screwdriver (adjusting
carburetor)
5 Screwdriver bit 0812 540 1112 Removing and installing spline socket
screws with electric or pneumatic
screwdrivers; tighten down screws with
torque wrench, releasing clutch drum
6 Wrench 4130 890 3600 Loosening clutch
7 Hook 5910 890 2800 Detaching springs on clutch shoes
8 Setting gauge 1127 890 6400 Adjusting air gap between the ignition
module and flywheel
9 Ignition system tester, ZAT 4 5910 850 4503 Testing ignition system
10 Ignition system tester, ZAT 3 5910 850 4520 Testing ignition system
11 Puller 5910 890 4400 Removing oil seals
- Jaws (No. 3.1 + 4) 0000 893 3706 Removing oil seal(s)
- Jaws (No. 2) 0000 893 3700 Holding engine pan on crankcase
- Threaded bushing 1108 893 4500 Preparing puller
12 Press sleeve 1129 893 2400 Installing oil seals
13 Hook 5910 893 8800 Removing pickup body
14 Press sleeve 1121 893 2400 Installing oil seals
15 Installing sleeve 4119 893 4600 Protects oil seal at starter side
No. Part Name Part No. Application Rem.
16 Clamping strap 0000 893 2600 Clamping ring around piston
17 Assembly drift 1130 893 4700 Removing and installing piston pin
18 Wooden assembly block 1108 893 4800 Supporting the piston
19 Installing tool 8 5910 890 2208 Installing hookless snap rings in piston
