3 Main Parts
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
NOTICE
Indicates a risk of property damage, including damage to the
machine or its individual components.
2.2 Symbols in Text
The following symbol is included to assist you with the use
of the manual:
3.1 Trimmer and Charger
The trimmer is powered by an integrated lithium ion battery
that cannot be removed from the power tool.
1 Control Handle
Handle for the operator's rear hand.
2 Trigger Switch Lockout
Must be depressed while the retaining latch is unlocked
to allow activation of the trigger switch.
3 Retaining Latch
Locks/unlocks the trigger switch.
4 Activation Key
Enables the flow of electrical power from the integrated
battery to the motor.
5 Activation Key Socket
Socket for connecting the activation key to the trimmer.
6Star Knob
Tightens the loop handle in position.
7Housing
Contains the integrated battery.
Refers to a designated chapter or sub-chapter in this
instruction manual.
3Main Parts
1 2
8
9
10
11
12
18
20
14
15
6
5
4
3
#
#
13
7
16
17
19
0000-GXX-1403-A1
