Stihl HT 101 - Starting; Stopping the Engine

HT 100, HT 101, HT 130, HT 131
English
26
HT 101, HT 131 only
N Put the backpack carrying
system (1) on your back and adjust
it as described in the instruction
sheet provided.
N Secure the sliding adjuster (2) to the
shaft.
N Attach the pole pruner to the
carrying strap when cutting.
N Adjust the hip belt (3), both shoulder
straps (4) and the carrying strap (5).
N Squeeze the grips to move the
sliding adjuster up or down the
shaft.
Controls
1 Throttle trigger lockout
2 Throttle trigger
3 Slide control
Positions of slide control
4STOP-0 – engine off – ignition is
switched off
5 F – normal run position – the engine
is running or can start
6START – ignition is switched on –
the engine can start
246BA010 KN
1
2
246BA011 KN
4
5
3
246BA012 KN
Starting / Stopping the
Engine
3
STOP
2
5
6
4
7
002BA181 KN
START
STOP-
1
