HT 100, HT 101, HT 130, HT 131
English
24
The saw chain must always throw off a
small amount of oil.
NOTICE
Never operate your saw without chain
lubrication. If the chain runs dry, the
whole cutting attachment will be
irretrievably damaged within a very short
time. Always check chain lubrication and
the oil level in the tank before starting
work.
Every new chain has to be broken in for
about 2 to 3 minutes.
After breaking in the chain, check chain
tension and adjust if necessary – see
"Checking Chain Tension".
HT 101, HT 131 only
WARNING
Always shut off the engine and fit the
chain guard
N Loosen the screw.
N Adjust shaft to the required length.
N Tighten down the screw firmly.
The type and style of the harness
depend on the market.
Shoulder strap
N Put on the shoulder strap (1).
N Adjust the length of the strap.
N With the power tool attached, the
carabiner (2) must be at about the
same height as your right hip.
Checking Chain Lubrication
390BA048 KN
Adjusting the Telescoping
Shaft
390BA049 KN
Fitting the Harness
2
1
390BA040 KN

Table of Contents

Other manuals for Stihl HT 101

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Stihl HT 101 and is the answer not in the manual?

Stihl HT 101 Specifications

General IconGeneral
Engine Type2-stroke
Displacement31.4 cc
Power Output1.05 kW
Overall Length270 cm
Vibration Level Left/Right4.5/4.5 m/s²
Guide Bar Length30 cm
Powerhead Weight6.6 kg
Fuel Tank Capacity530 cc
Oil Tank Capacity0.2 liters
