Stihl HT 101 User Manual

56 Series 4180 Powerhead
Check the flywheel:
Have pole shoes turned blue?
Install new flywheel
Check air gap
and reset if necessary
Check the ignition lead:
– Severe chafing?
– Spark plug boot: Holes/cracks?
– Resistance: spark plug boot to ground: spec.
1.5 – 12 kΩ
– Check resistance of ignition lead
Spec.: < 10 Ω,
If necessary, install new spark plug boot and/or
ignition lead,
if ignition lead is molded to ignition module:
– Install new ignition module
Disconnect short circuit wire
from ignition module
1
3
yes
no
2
Ignition
spark?

Stihl HT 101 Specifications

General

Engine Type	2-stroke
Displacement	31.4 cc
Power Output	1.05 kW
Overall Length	270 cm
Vibration Level Left/Right	4.5/4.5 m/s²
Guide Bar Length	30 cm
Powerhead Weight	6.6 kg
Fuel Tank Capacity	530 cc
Oil Tank Capacity	0.2 liters
