12. Special Accessories
No. Part Name Part No. Application
1 Lubricating grease (225 g tube) 0781 120 1111 Oil seals
2 Press fluid OH 723
(50 ml and 100 ml bottle)
0781 957 9000 Rubber elements of AV system
Fuel line connector
Grommet on molded hose
(one-part system)
3 STIHL special lubricant 0781 417 1315 Bearing bore in rope rotor,
bearing bore in rope rotor
4 Dirko HT red sealant
(90 g tube)
0783 830 2000 Crankcase sealing faces
5 Electrician’s repair kit 5910 007 1050 Electrical system
6 Set of screws 5910 007 1060 Screwed assemblies
7 Standard commercial solvent-
based degreasant containing no
chlorinated or halogenated
hydrocarbons
Cleaning crankshaft stubs and flywheel taper

Stihl HT 101 Specifications

General

Engine Type	2-stroke
Displacement	31.4 cc
Power Output	1.05 kW
Overall Length	270 cm
Vibration Level Left/Right	4.5/4.5 m/s²
Guide Bar Length	30 cm
Powerhead Weight	6.6 kg
Fuel Tank Capacity	530 cc
Oil Tank Capacity	0.2 liters
